• Width: 240 mm (9.45 in.)

• Height: 77 mm (3.03 in.)

• Weight: 1 kg (2.21 lbs.)

• Color: Licorice black

• Anti-theft protection: Kensington security slot

• Screen resolution: 128 x 64 pixels (5 in. x 2.5 in.)

• Backlit black/white LCD display

• Keys:

  ¬ Alphanumeric 0–9, *, #

  ¬ On, off

  ¬ Call, call hold, end call

  ¬ Mute, volume +/-

  ¬ Contacts

  ¬ Conference guide

• Five keys for menu navigation

• Protocols: SIP, LDAP (RFC1777)

• During a call:

  ¬ Put call on hold

  ¬ Call waiting

  ¬ Call park and pick-up

  ¬ Transfer incoming call

  ¬ Request

  ¬ Music on hold

  ¬ Dial plan

• Dialing methods:

  ¬ Phone number

  ¬ SIP URI

  ¬ ALE Unite mobile app

• Multi-party calls:

  ¬ Local five-way audio bridge

  ¬ Two configurable SIP accounts

• Phone book:

  ¬ LDAP

  ¬ Four password-protected user profiles

  ¬ Local directory: Up to 1000 entries per user profile

  ¬ Export/import of contacts

  ¬ Call list

  ¬ Conference guide: 20 groups per user profile, four participants/ group

• Call recording: Support for SD and SDHC memory cards

• Technology:

  ¬ OmniSound with support for HD audio

  ¬ Full duplex

  ¬ Automatic echo cancellation

  ¬ Noise suppression

• Microphone:

  ¬ Omnidirectional 360˚ reception area

  ¬ Up to 12 people (30 m2)

  ¬ Optional two expansion microphones (70m2)

• Speakers:

  ¬ Frequency range: 200-20,000 Hz

  ¬ Volume: max. 90 dB

  ¬ Sound pressure level (SPL): 0.5 m

• Equalizer: Soft, neutral, bright

• Codecs: G722, G711 A-law, G711 μ-law, G729ab

• Bluetooth

  ¬ Low Energy Profiles

  ¬ GAP and GATT

  ¬ Only for control features, not for audio transfer

• NFC for swift connection to the ALE Unite mobile app

  ¬ NFC Forum Type 4

  ¬ ISO/IEC 14443 Type A support

• USB: 2.0 Mini B port

• Expansion microphones: 2x modular 4/4

• ALE Unite

  ¬ Meeting notification before meeting starts

  ¬ Discovery of nearest 8135s IP Conference Phone: Bluetooth, NFC

  ¬ One touch conferencing

  ¬ Meeting management: Add participants, dial with keypad, mute, hold, split, hang-up

  ¬ Android: Google Play

  ¬ iOS: Apple Store

• SIP v2

• DNS SRV (RFC3263)

• NAT traversal: STUN, ICE and TURN

• Connection protocol: SIP 2.0 (RFC 3261 and companion RFCs)

• Signaling protocol: UDP, TCP, TLS and SIPS

• Media protocol: RTP, SRTP

• DTMF tone generation: RFC 4733/2833, SIP INFO, In-band

• Alcatel-Lucent OmniPCX Enterprise R12.0 and above

  ¬ Communication Server redundancy

  ¬ Passive Communication Server local redundancy

• Alcatel-Lucent OXO Connect 3.1 and above

• Ethernet 10/100BaseT (IEEE 802.3ab)

• IEEE 802.3af Power over Ethernet (POE), ANSI/TIA-1057 (LLDP-MED)

• DHCP and static IP

• 802.1x Authentication with EAP-TLS

• QoS support: IEEE 802.1p/Q (VLAN), DiffServ

• Configuration methods: Browser (HTTP/HTTPS)

• Support for auto-provisioning with certificate management

• Time servers: NTP and SNTP (RFC4330)

• Additional features: Remote syslog, PCAP-log, unique hostname

• TFTP/HTTP/HTTPS

• IEEE 802.3af Power over Ethernet (POE) Class III

• Power supply: 100-240 V AC/ 13.5 V DC

• Multi-language support (menu): Danish, Dutch, English, Finnish, French, German, Italian, Norwegian, Polish, Russian, Spanish, Swedish and Turkish

• Operating temperature: +5° C (+41° F) / +40° C (+104° F)

• Relative humidity: 20% to 80% condensation-free

• EN 60950-1:2006

• IEC/UL/CSA 60950-1

• EN 301 489-17

• EN 301 489

• EN 301 489-1

• FCC Part 15 subpart B class B

• ICES-003 class B

• EN 55032

• EN 55024 + A1

• EN 61000-3-2

• EN 61000-3-3

• EN 300 328

• FCC Part 15 subpart C

• RSS-210

• EN 62311

• FCC KDB447498

• RSS-102

• 3MG08015AA:

  ¬ 8135s IP Conference Phone

  ¬ 6.5 m (21 ft.) network cable

  ¬ Safety sheet

• 3MG07040AA

  ¬ 8135s IP Conference Phone

  ¬ 6.5 m (21 ft.) network cable

  ¬ Power supply

  ¬ Two expansion microphones

  ¬ Safety sheet

• Power supply: 3GV28133AA

• Two expansion microphones: 3GV28134AA

  ¬ 1.5 m (5 ft.) cable and 2.5 m (8 ft.) cable included

  ¬ Increase the range from 30 m2 to 70 m2, that is more than double the range

8135s IP Conference Phone datasheet
